Cart Transform: Update Lines Operation

Cart Transform: Update Lines Operation

Modify the price, title, and image of cart line items

Overview

The Update Lines block modifies the properties of cart line items — including their price, title, and image. Changes appear immediately in the customer’s cart.

  • Dynamic pricing — apply custom prices based on metafields, attributes, or mapping rules
  • Product customization — change titles and images based on customer selections
  • Personalization — display customized product information in the cart
  • Conditional pricing — apply different prices based on product attributes
Warning

Update operations are supported only on Shopify Plus stores.

Two Methods

The Update Lines block supports two configuration methods:

  • Manual configuration — set price, title, and image individually using static values or linked fields
  • Attribute-based configuration — load all values dynamically from a single JSON cart line attribute

Setup

Open your cart transform function

Navigate to the function you want to edit in Function Studio

Add the Update Lines block

Click Add Action and select Update Lines from the action list

Configure the block

Set the options described in the Settings section below

Settings

Cart Line Groups

Required

Select which groups of cart lines should be updated. Groups must be defined earlier in your function using a Define Cart Line Groups block.

Price Mapping

Optional

Select a mapping variable to apply dynamic prices based on mapping rules. When selected, this overrides any static or field-based price settings.

This dropdown shows output variables created by Variant Price Mapping blocks placed earlier in your function. When a mapping is selected, per-unit prices are looked up from a CSV-format metafield at runtime.

If no Variant Price Mapping blocks exist in your function, the UI shows “No mapping variables available.”

Tip

To use price mapping, add a Variant Price Mapping block before the Update Lines block. See Variant Price Mapping below for configuration and the CSV format.

Load All Fields from Attribute

When enabled, price, title, and image are all read from a JSON attribute on each cart line instead of being set individually. The individual field settings below are hidden.

See Attribute-Based Configuration for the JSON format.

Attribute Key

Shown when Load All Fields from Attribute is enabled

The cart line attribute key to read data from. Defaults to _update.

Load Price from Field

Shown when not loading from attribute

When enabled, the price value is read from a metafield, cart attribute, or other field instead of using a fixed value. The fixed price input is replaced with a field selector.

Supported field sources:

  • Product Metafields — read price from a product-level metafield
  • Variant Metafields — read price from a variant-level metafield
  • Cart Line Attributes — read price from a line item property
  • Standard Fields — use a built-in numeric field (e.g., quantity, unit price)

Price

Shown when not loading from attribute or field

Set a fixed price per unit for all items in the selected groups. Leave empty to keep the original price.

Title

Optional · Shown when not loading from attribute

Override the product title shown to customers. Leave empty to keep the original title.


Optional · Shown when not loading from attribute

Select a custom product image. Leave empty to keep the original image.

Attribute-Based Configuration

For maximum flexibility, load all fields from a single cart line attribute containing a JSON object.

JSON Structure

{
  "price": "34.56",
  "title": "Custom Product Title",
  "image": "https://cdn.shopify.com/path/to/image.png"
}

All fields are optional — omit any field to keep its original value.

price

Optional

New price per unit. Must be a string representation of a decimal number (e.g., "29.99").

title

Optional

New display title for the cart line.


Optional

New image URL for the cart line.

Setting the Attribute

In Product Forms (Liquid Templates)

<input type="hidden" name="properties[_update]" value='{"price":"34.56","title":"Custom Product"}'>

Via Ajax Cart API

{
  "id": "12345",
  "qty": 1,
  "properties": {
    "_update": '{"price":"34.56","title":"Custom Product","image":"https://example.com/image.png"}'
  }
}

Through apps or scripts — set the property when adding items to cart programmatically. Useful for product configurators and customization tools.

Variant Price Mapping

The Variant Price Mapping block parses a CSV metafield into a reusable mapping variable. Place it before an Update Lines block, then select the output variable in the Update block’s Price Mapping field to apply dynamic per-unit prices.

Prices are looked up at runtime using a composite key built from one or more mapping levels (for example, market ID or currency code) combined with the cart line quantity.

Block Settings

Variable Name

Required

Name of the output variable that stores the parsed mapping (e.g., priceMapping). This is what appears in the Price Mapping dropdown of downstream blocks.

Metafield

Required

The product or variant metafield containing the CSV mapping data. The metafield must be a string type.

Mapping Levels

Optional

An ordered list of fields used to build the lookup key. Common examples:

  • Market ID — different prices per Shopify market
  • Currency code — different prices per currency
  • Customer tag or company location — B2B pricing tiers

At runtime, each level is resolved and the values are joined to form the key that’s matched against the first column of the CSV. If you don’t configure any mapping levels, the first CSV column should be a fixed identifier you control (see the single-level example below).

CSV Format

For Update Lines, each CSV line uses a 3-part format separated by pipes (|):

<level_combo>|<qty_range>|<price>
  • level_combo — the resolved mapping-level values, joined in the configured order (no separator between levels). Must match exactly.
  • qty_range — either min-max (inclusive on both ends) or a single min value (interpreted as min to unlimited).
  • price — per-unit price as a decimal number (e.g., 29.99).

The first line whose level_combo matches and whose qty_range contains the cart line quantity is used. If no line matches, the cart line’s price is left unchanged.

Note

Lines that don’t have exactly 3 parts are skipped. This lets you store both l_update (3-part) and l_expand (4-part) mappings in the same metafield — each block picks the lines that apply to it.

Example Metafield Value

Single market, volume tiers — one mapping level resolving to a market ID (gid://shopify/Market/101904318728, numeric 101904318728):

101904318728|1-4|29.99
101904318728|5-9|24.99
101904318728|10|19.99

Cart line quantity 1–4 → $29.99 each, 5–9 → $24.99 each, 10 or more → $19.99 each.

Multiple markets, flat pricing — same mapping level, different keys per row:

101904318728|1|29.99
205817493032|1|34.99

Two mapping levels — market ID plus currency code, concatenated into the key column:

101904318728USD|1-4|29.99
101904318728USD|5|24.99
101904318728EUR|1-4|27.50
101904318728EUR|5|22.50
Tip

CSV content is typically stored as a multi-line string metafield. Use the \n newline separator — the block trims whitespace on each line.

Examples

Example 1: Fixed Price Override

Apply a promotional price to all items in a specific collection.

Create a cart line group

Add a “Define Cart Line Groups” block with group name PROMO_ITEMS matching products in the “Summer Sale” collection

Add the Update block

Select Update Lines, set Cart Line Groups to PROMO_ITEMS, and enter 19.99 as the Price

Result

All items in the “Summer Sale” collection are repriced to $19.99

Example 2: Price from Variant Metafield

Use a custom price stored in a variant metafield.

Set up metafields

Add a variant metafield custom.promo_price (type: number_decimal) with different values per variant

Create the group and block

Add a “Define Cart Line Groups” block for the target products, then an “Update Lines” block

Enable field-based pricing

Turn on Load price from field, select Variant Metafield, and choose custom.promo_price

Result

Each variant uses its own promotional price from the metafield

Example 3: Dynamic Customization with Attributes

A customer personalizes a product with custom text and image.

Set the attribute on add-to-cart

Your theme or app sets _update property with JSON: {"price":"45.00","title":"Personalized Mug - Sarah","image":"https://cdn.shopify.com/generated/sarah-mug.png"}

Create the group

Add a “Define Cart Line Groups” block with group name PERSONALIZED matching items with the _update attribute

Enable attribute loading

In the Update Lines block, turn on Load all fields from attribute with attribute key _update

Result

Cart line displays custom title, image, and price based on the personalization

Example 4: Volume-Tiered B2B Pricing with Price Mapping

Different markets see different volume-discount tiers for the same variant.

Store the CSV on the variant

Add a variant metafield custom.price_tiers (type: single-line text or multi-line text) with content like:

101904318728|1-4|29.99 101904318728|5-9|24.99 101904318728|10|19.99 205817493032|1-4|34.99 205817493032|5|28.99

Add a Variant Price Mapping block

Set Variable Name to priceMapping, select the custom.price_tiers metafield, and add one Mapping Level resolving to the current market ID

Add the Update block

Create a cart line group for the target products, add an Update Lines block, and set Price Mapping to priceMapping

Result

At checkout, each line’s price is looked up using the active market ID plus the line quantity — the first matching CSV row wins

Best Practices

Pricing Strategy

  • Use metafield-based pricing when different products need different prices without creating separate functions
  • Use Price Mapping when you need quantity-based or market-based pricing tiers from a CSV metafield
  • Set prices as string values in attribute JSON (e.g., "29.99" not 29.99)

Attribute-Based Loading

  • Use a consistent attribute key across your store (the default _update works well)
  • Validate JSON format before setting the attribute — invalid JSON is silently ignored
  • Only include fields you want to change — omit fields to keep original values

Customer Experience

  • Use meaningful titles so customers understand any price changes
  • Provide updated images when the visual appearance of the product changes
  • Test the checkout experience with updated lines

Important Considerations

Plan Requirements

  • Update operations require Shopify Plus
  • The block shows a warning banner if used on a non-Plus store

Cart Behavior

  • Updated values appear immediately in the customer’s cart
  • Original product data is preserved in Shopify — only the cart presentation changes
  • Cart totals reflect the updated pricing
  • Leave fields empty to keep original values

Price Mapping Precedence

  • When a Price Mapping variable is selected, it overrides both static prices and field-based prices
  • If the mapping doesn’t find a match for a given line, the line’s price is not changed

Function Flow Requirements

  • Cart line groups must be defined before the Update Lines block
  • Variant Price Mapping blocks must be placed before the Update Lines block if using price mapping
  • Updates apply to the current cart session

Troubleshooting

Updates Not Applying

  • Check your groups — make sure cart line groups are defined before the Update Lines block
  • Verify plan — Update operations require Shopify Plus
  • Check for empty values — empty fields are intentionally ignored (original value kept)

Price Not Changing

  • Check Price Mapping — if a mapping variable is selected, it overrides static and field-based prices. Try setting the mapping dropdown to “No mapping” to test
  • Verify field source — when using “Load price from field,” ensure the metafield exists and has a numeric value
  • Check attribute format — when using attribute-based loading, price must be a string (e.g., "29.99")

Attribute-Based Loading Not Working

  • Check JSON format — ensure the attribute value is valid JSON
  • Verify attribute key — confirm the key matches what’s configured (default: _update)
  • Check attribute is set — verify the property is actually present on the cart line
  • Test individual fields — try setting only price first to isolate issues
